Hot rolled sheet - prices updated 28.11.2018 to 8:59
Hot rolled sheet is available in our various branches, you can choose the branch you need, the type and size of products and order online:
Presents the actual prices for metal. Hot rolled sheet is available in our various branches, you can choose the branch you need, the type and size of products and order online. Attention Prices are subject to prepayment! There is a surcharge for a batch of less than 1 ton, more details from the manager.
Product Name | Size | Length | Other | Weight 1 PC/kg. |
On stock (ton) |
Price 1 PC |
Price 1 - 5 tons |
Price от 5 - 15 tons |
Price > 15 tons |
Branch | Товаров нет |
---|
Hot rolled sheet - техническая информация: |
Hot rolled sheet.
(Hot rolled sheet and coiled steel) GOST 19903-74, GOST 19903-90
Sheets less than 3mm have a cutting of 1250 * 2500, a steel sheet of 3 mm can have a cutting of both 1250 * 2500 and 1500 * 6000, more than 4 mm mainly - 1500 * 6000 and 2000 * 6000.
Hot-rolled sheet production
Hot-rolled sheets are steel sheets that take the form of a plate after rolling billet steel slabs in a hot condition.
Hot-rolled (hot-rolled) sheets are used in construction, industry, mechanical engineering, machine-tool construction, shipbuilding, military and civil aviation, architecture, for the manufacture of metal structures of various moods, appliances, household appliances, etc. The hot-rolled sheet is used for further processing, it is subjected to drawing and cutting to obtain a expanded metal sheet. Expanded metal sheet is used for the production of steps of stairs, street barriers, various packaging. Also, hot-rolled steel sheets are used in the production of electric-welded and shaped pipes, welded beams, angles.
Hot-rolled metal sheet 2 mm, hot-rolled metal sheet 3 mm, hot-rolled metal sheet 4 mm, hot-rolled metal sheet 5 mm, hot-rolled metal sheet 6 mm, hot-rolled metal sheet 10 mm, hot-rolled metal sheet 20 mm - widely used in machine building, construction, metallurgy . Major suppliers of hot-rolled sheet metal
AO Novolipetsk Iron and Steel Works (NLMK) (sheet up to 12mm inclusive), AO Chelyabinsk Metallurgical Plant (Mechel) (more than 10mm), AO Severstal , AO Ashinsky Metallurgical Plant , AO Magnitogorsk Metallurgical Plant (MMK), AO "Ural Steel", AO "Zaporozhye Metallurgical Plant" Zaporizhstal" (Ukraine), AO " Metallurgical Plant "Azovstal".
GOST 16523 -97 hot-rolled thin steel sheet is made from high-quality steel and ordinary steel quality: 08ps, 10ps, St 1ps, St3ps, etc.
Hot rolled plates are made:
1)sheet GOST 14637-89 - carbon steel of ordinary quality.
The standard prescribes technical requirements. Hot-rolled sheet GOST 14637-89 - rolled plate of carbon steel of ordinary quality, manufactured with a width of 500 mm and more, 4-160 mm thick, inclusive. Thickness 4 -160 mm is available in sheets, from 4 to 12 mm - in rolls. This sheet is made of steel grades: St0, St2kp, St2sp, St2ps, St3kp, St3ps, St3sp, St3Gps, St3Gsp, St4ps, St4ps, St5ps, St5sp, St5Gps.
According to normalized characteristics, they are divided into 6 categories (the number is added after the steel grade designation): 1 (St2sp1, St3kp1), 2, 3, 4, 5, 6
The remaining characteristics of the rolled product range must comply with GOST 19903 (hot-rolled sheet metal).
Sheet steel 3 is welded without restrictions. Sheet Art. 3 is applicable for bearing welded and non-welded structures.
2) according to GOST 19281-89 - high strength steel: 17GS, 09G2, 09G2C sheet , etc. This standard describes the general technical conditions.
In the OK300V marking, the letters OK signify flat rolled stock of ordinary quality, the number 300 is the lower limit of resistance.
– according to GOST 1577 -93 - structural quality steel grade 08kp, steel sheet 20 and steel sheet 35 , sheet 40X , sheet steel 45 , 10, 15kp, 50G 70G, 65G, 20X. In GOST specifications of steel are prescribed. From the sheet article 20 made seamless pipe and cold. This sheet is used in mechanical engineering and construction, as supporting metal structures, etc.Art. 35 sheet used for industrial fasteners. Steel 35 is more resistant to corrosion than steel 20. Sheet steel 40X has high endurance, but difficult to weld. Sheet steel 45 is resistant to temperature extremes.
Steel grade 65Г , its chemical composition is standardized by GOST 14959 79 , which applies to spring-spring structural steel. Sheets on steel 65G have increased strength, toughness and durability. From the steel sheet 65G manufactured throwing blades and Cossack checkers due otlichnm cutting properties.
3) According to GOST 11269 - structural high-quality alloyed steel 30HGSA (specifications in GOST). The quality of steel is characterized by a carbon content of up to 0.034%, chromium about 1%, manganese up to 1.1% and silicon. The letter A in the steel mark indicates improvement: quenching with rapid heating to 870 degrees, and then immediate cooling. Alloying (dopant) components sheet steel 30HGSA provide impart mechanical strength, anti-corrosion properties, increase impact strength, give resistance to stress. Technical terms of delivery of sheet steel grades sheet 65G and 30HGSA sheet are also indicated in TU 14-1-4118-04.
Steel sheet GOST 19903 - hot rolled (hot-smoked) sheet steel is manufactured:
500 mm wide and more, 0.4 - 160 mm thick - in sheets,
1.2 - 12 mm thick - in rolls.
Hot Sheet steel grades are:
a) according to rolling accuracy with thickness up to 12 mm:
- increased accuracy - A
- normal accuracy - B
b) flatness:
- specially high - software
- high - PV
- improved - PU
- normal flatness - PN
c) by the nature of the edge:
- with not cut edge - BUT
- with a cut edge - O
d) by the value of temporary resistance (B). In the OK300V marking, the letters OK signify flat rolled stock of ordinary quality, the number 300 is the lower limit of resistance.
An example of marking a hot rolled thin sheet:
Sheet A - PN - BUT - 3x1500x6000 GOST 19903-74
315 - st3sp5 - GOST 16523-97
These are hot-rolled thin sheets, increased rolling strength (A) and normal flatness (ПН), with uncut edge (HO), 3x1500x6000, GOST on hot-rolled sheet 19903-74, strength steel grade 315, steel grade St3sp5 and GOST for thin-sheet steel - 16523 -97.
Hot-rolled steel sheet GOST 19903-74.
Main dimensions, weight m2 of hot-rolled steel sheet (the entire GOST 19903 can be viewed here ...)
Thickness of steel sheet, mm |
Sheet width, mm |
Weight of 1 m steel sheet, kg |
1,50 |
1250 |
14,72 |
Steel sheet 2 mm |
1250 |
19,63 |
Steel sheet 3 mm |
1250 |
29,44 |
3,00 |
1500 |
35,33 |
Steel sheet 4 mm |
1500 |
47,10 |
Steel sheet 5 mm |
1500 |
58,88 |
Steel sheet 6 mm |
1500 |
70,65 |
Steel sheet 8 mm |
1500 |
94,20 |
Steel sheet 10 mm |
1500 |
117,75 |
2000 |
157,00 | |
12,00 |
1500 |
141,30 |
2000 |
188,40 | |
14,00 |
1500 |
164,85 |
1800 |
197,82 | |
2000 |
219,80 | |
16,00 |
1500 |
188,40 |
2000 |
251,20 | |
18,00 |
1500 |
211,95 |
1600 |
226,08 | |
Steel sheet 20 mm |
1500 |
235,50 |
2000 |
314,00 | |
22,00 |
1500 |
259,05 |
24,00 |
1500 |
282,60 |
25,00 |
1500 |
294,38 |
2000 |
392,50 | |
28,00 |
1500 |
329,70 |
30,00 |
1500 |
353,25 |
32,00 |
1500 |
376,80 |
2000 |
502,40 | |
36,00 |
1500 |
423,90 |
1900 |
536,94 | |
2000 |
565,20 | |
40,00 |
1500 |
471,00 |
2000 |
628,00 | |
50,00 |
1500 |
588,75 |
2000 |
785,00 | |
60,00 |
1500 |
706,50 |
2000 |
942,00 | |
80,00 |
1500 |
942,00 |
2000 |
1256,00 | |
90,00 |
1500 |
1059,75 |
1600 |
1130,40 | |
2000 |
1413,00 | |
100,00 |
1600 |
1256,00 |
120,00 |
1600 |
1507,20 |
Buy hot-rolled steel sheet
You can purchase steel sheet of all types produced from us, 30HGSA to buy, 65g sheet to buy from the warehouses of branches, warehouses of the Moscow region or directly from the factory. We provide services for metal sheet cutting , delivery and picking. Availability, sheet of hot-rolled steel dimensions, weight and price list of steel you can see on the website. For more information on the price of hot-rolled steel sheet per piece, specify the weight of hot rolled sheet . steel and make a calculation of the quantity, draw up an invoice and make a request, clarify payment options and request a certificate for a hot - rolled sheet - please contact the manager by contacting him by phone
