Cold-rolled sheet GOST 19904-90, GOST 19904-74
(Cold rolled sheet and coiled steel)

View price - Cold rolled sheet

Sheet cold-rolled steel with a width of 500 mm and more is manufactured with a thickness of 0.35 - 5 mm in sheets, with a thickness of 0.35 - 3.5 mm - in rolls.
Sheets less than 3mm have a cutting of 1250 * 2500, more than 4mm inclusive - 1500 * 6000.

It is used for cold stamping and manufacturing of products with high surface quality, as well as in construction, engineering, instrument making, shipbuilding, aircraft building, electric power industry, for the manufacture of agricultural machinery. In the construction of cold-rolled sheet is used when tightening structures of special strength. Is often used in the processing of industry- sheet x / k manufactured sheet and galvanized sheet metal coated , perforated metal sheet , profiled. Also cold-rolled sheet is used as raw material for profile metal wall sheets and metal tiles.

Production of cold rolled sheet:
By means of hot rolling, a roll is made, then a process of pickling a hot-rolled steel sheet, where special chemicals act on the metal, takes place. Later, the metal is rolled under high pressure in a cold rolling mill and either left a sheet or formed into a roll. If necessary, to give the sheet certain physical properties, it is also subjected to compression. Such technology of manufacturing cold-rolled metal sheets allows to obtain a thinner layer with high performance properties, because of this, cold-rolled sheet is more expensive than hot-rolled sheet, it is characterized by plasticity and a smoother surface.

Cold rolled sheet suppliers: OAO Novolipetsk Metallurgical Plant (NLMK), OAO Severstal.

Cold-rolled steel sheet (hk) is made from high-quality steel and ordinary steel quality:

• carbon steel - 08ps, 08kp, 10, 15ps, 15, 20ps, St 1ps, St2ps, St2sp, St3ps, St3sp according to GOST 16523-97 for general use;
• low carbon steel - 08ps, 08kp, 08yu according to GOST 9045-93- for cold forming.

Cold rolled sheets produce

1. by rolling accuracy:

a) in thickness:

• high - W
• increased - AT
• normal accuracy - BT

b) in width:

c) by length:

• high - VD
• increased - blood pressure
• normal - DB

2. flatness:

• especially high - software
• high - PV
• improved - PU
• normal - PN

3. by the nature of the edge:

• unedged - BUT
• edged - About

4. on the ability to extract:

• normal - N (not used)
• deep - G (not used)
• very deep - SH (steel 08yu)
• difficult - SV
• especially difficult - WWS

5. on the quality of surface finish:

• especially high
• high
• increased
• ordinary

6. on the surface: can be matte and glossy

Example of marking a cold rolled sheet:

The sheet BT - PV - O - 0,8x1250x2500 GOST 19904-74
II - VG-08Yu GOST 9045-93

This is a cold-rolled sheet of normal rolling accuracy in thickness (BT), high flatness (PV), cut edge, 0.8 mm thick, 1250 mm wide, 2500 mm long, according to GOST on a range of 19904-74, high surface finish (II), very deep drawing (VG), from 08yu steel, according to GOST 9045-93 (cold-rolled thin sheets for cold forming).

Cold-rolled steel sheet GOST 19904-90 , GOST 19904-74.
Main dimensions, weight of cold-rolled sheet

Buy cold rolled sheet

You can buy a cold-rolled sheet of all types produced from our warehouses of branches, warehouses of the Moscow region or directly from the factory. We provide services for cutting, delivery and completion of the sheet. Availability, assortment of cold-rolled sheets and the price list of metal sheet you can see on the website. For more information on the price of cold-rolled steel sheet , specify the weight of the sheet and make the calculation of the quantity, draw up an invoice and make a request, clarify payment options and request a certificate for the metal already taken - you can from the manager by contacting him by phone

(8452) 57-00-18, e-mail: korneev@metallotorg.ru
